Spring Boot Webflux DynamoDB Tutorial

Spring Boot Webflux DynamoDB Tutorial

1. Overview

Spring Boot Webflux DynamoDB Tutorial – Let us integrate AWS DynamoDB with Spring Boot Webflux. In this tutorial will be try to integrate DynamoDB with Webflux in Spring Boot. Instead of using the default AWS Sync Client which blocks the thread, we will use Async client with Webflux.

We are going to create a REST API with basic CRUD operations on a Customer entity. The customer record will be stored in AWS DynamoDB. Also we will use Webflux to connect with DynamoDB.

2. Project Structure

Let’s start by bootstrapping a new Spring Boot project using start.spring.io. Following project settings were selected in start.spring.io.

  • Project: Gradle Project
  • Language: Java
  • Spring Boot: 2.2.2
  • Dependencies: Spring Reactive Web

Once generated, import the project in your favorite IDE.

Update the build.gradle file as following. We have added awssdk dynamodb 2.10.40 through dependencyManagement. Also note that spring-boot-starter-weblux is on classpath.

build.gradle

plugins { id 'org.springframework.boot' version '2.2.2.RELEASE' id 'io.spring.dependency-management' version '1.0.8.RELEASE' id 'java' } group = 'net.viralpatel' version = '0.0.1-SNAPSHOT' sourceCompatibility = '11' repositories { mavenCentral() maven { url 'https://s3-us-west-2.amazonaws.com/dynamodb-local/release' } } dependencies { implementation 'org.springframework.boot:spring-boot-starter-webflux' implementation 'software.amazon.awssdk:dynamodb' testImplementation('org.springframework.boot:spring-boot-starter-test') { exclude group: 'org.junit.vintage', module: 'junit-vintage-engine' } testImplementation 'io.projectreactor:reactor-test' } dependencyManagement { imports { mavenBom 'software.amazon.awssdk:bom:2.10.40' } } test { useJUnitPlatform() }

Add following configuration in application.yaml file. We have defined a couple of properties for dynamodb endpoint and table name. Note the endpoint is pointing to our local DynamoDB. In production you might want to change this to point to your AWS region. We can also use Spring profiles to switch the value for this properties in different environment.

application.yaml

application: dynamodb: endpoint: http://localhost:8000 customer_table: customers

Following is the directory structure for our REST API project. Note that the customer related classes are segregated in a customer package.

Spring Boot Webflux DynamoDB Project Structure

3. Setting up DynamoDB Locally without Docker

Before we proceed with the rest of tutorial, we will setup a local dynamodb instance where we can test our changes. Instead of relying on AWS environment for DynamoDB this would speed up the development process.

We will create customers table in local DynamoDB. Follow the steps at https://docs.aws.amazon.com/amazondynamodb/latest/developerguide/DynamoDBLocal.DownloadingAndRunning.html

  1. Download the AWS DynamoDB Local JAR from above link and unzip it
  2. Run the local dynamodb jar
    java -Djava.library.path=./DynamoDBLocal_lib/
             -jar DynamoDBLocal.jar
  3. Create customer table in dynamodb.
    aws dynamodb create-table
        --table-name customers
        --attribute-definitions AttributeName=customerId,AttributeType=S
        --key-schema AttributeName=customerId,KeyType=HASH
        --provisioned-throughput ReadCapacityUnits=5,WriteCapacityUnits=5
        --endpoint-url http://localhost:8000
  4. Verify the table is created.
    aws dynamodb list-tables
        --endpoint-url http://localhost:8000
    Output:
    {
          "TableNames": [
              "customers"
          ]
    }

4. REST API in Spring Boot Webflux DynamoDB

Let us start by defining the Repository and DynamoDB configuration to access the data from DynamoDB. As noted earlier we will use DynamoDbAsyncClient to access DynamoDB.

4.1 Repository with AWS Async Client

The repository class contains basic CRUD methods to maintain Customer entity. Note how we use dynamoDbAsyncClient to access DynamoDB using different GetItemRequest, DeleteItemRequest, ScanRequest APIs. Also we map the return type from DynamoDbAsyncClient which is CompletableFuture to Reactor’s Mono class using Mono.fromCompletionStage.

CustomerRepository.java

package net.viralpatel.springbootwebfluxdynamodb.customer; import org.springframework.beans.factory.annotation.Value; import org.springframework.stereotype.Repository; import reactor.core.publisher.Flux; import reactor.core.publisher.Mono; import software.amazon.awssdk.services.dynamodb.DynamoDbAsyncClient; import software.amazon.awssdk.services.dynamodb.model.*; import java.util.Map; import java.util.UUID; @Repository public class CustomerRepository { private DynamoDbAsyncClient dynamoDbAsyncClient; private String customerTable; public CustomerRepository(DynamoDbAsyncClient dynamoDbAsyncClient, @Value("${application.dynamodb.customer_table}") String customerTable) { this.dynamoDbAsyncClient = dynamoDbAsyncClient; this.customerTable = customerTable; } public Flux<Customer> listCustomers() { ScanRequest scanRequest = ScanRequest.builder() .tableName(customerTable) .build(); return Mono.fromCompletionStage(dynamoDbAsyncClient.scan(scanRequest)) .map(scanResponse -> scanResponse.items()) .map(CustomerMapper::fromList) .flatMapMany(Flux::fromIterable); } public Mono<Customer> createCustomer(Customer customer) { customer.setId(UUID.randomUUID().toString()); PutItemRequest putItemRequest = PutItemRequest.builder() .tableName(customerTable) .item(CustomerMapper.toMap(customer)) .build(); return Mono.fromCompletionStage(dynamoDbAsyncClient.putItem(putItemRequest)) .map(putItemResponse -> putItemResponse.attributes()) .map(attributeValueMap -> customer); } public Mono<String> deleteCustomer(String customerId) { DeleteItemRequest deleteItemRequest = DeleteItemRequest.builder() .tableName(customerTable) .key(Map.of("customerId", AttributeValue.builder().s(customerId).build())) .build(); return Mono.fromCompletionStage(dynamoDbAsyncClient.deleteItem(deleteItemRequest)) .map(deleteItemResponse -> deleteItemResponse.attributes()) .map(attributeValueMap -> customerId); } public Mono<Customer> getCustomer(String customerId) { GetItemRequest getItemRequest = GetItemRequest.builder() .tableName(customerTable) .key(Map.of("customerId", AttributeValue.builder().s(customerId).build())) .build(); return Mono.fromCompletionStage(dynamoDbAsyncClient.getItem(getItemRequest)) .map(getItemResponse -> getItemResponse.item()) .map(CustomerMapper::fromMap); } public Mono<String> updateCustomer(String customerId, Customer customer) { customer.setId(customerId); PutItemRequest putItemRequest = PutItemRequest.builder() .tableName(customerTable) .item(CustomerMapper.toMap(customer)) .build(); return Mono.fromCompletionStage(dynamoDbAsyncClient.putItem(putItemRequest)) .map(updateItemResponse -> customerId); } }

In following configuration class we create an instance of DynamoDbAsyncClient. Note how we mapped the endpoint from the application.yaml using Spring @Value annotation.

DynamoDBConfig.java

package net.viralpatel.springbootwebfluxdynamodb.config; import org.springframework.beans.factory.annotation.Value; import org.springframework.context.annotation.Bean; import org.springframework.context.annotation.Configuration; import software.amazon.awssdk.auth.credentials.DefaultCredentialsProvider; import software.amazon.awssdk.services.dynamodb.DynamoDbAsyncClient; import java.net.URI; @Configuration public class DynamoDBConfig { @Bean public DynamoDbAsyncClient dynamoDbAsyncClient( @Value("${application.dynamodb.endpoint}") String dynamoDBEndpoint) { return DynamoDbAsyncClient.builder() .endpointOverride(URI.create(dynamoDBEndpoint)) .credentialsProvider(DefaultCredentialsProvider.builder().build()) .build(); } }

Below is a utility class to map response from DynamoDB into our Customer entity class and vice versa. It’s just a boilerplate code.

CustomerMapper.java

package net.viralpatel.springbootwebfluxdynamodb.customer; import software.amazon.awssdk.services.dynamodb.model.AttributeValue; import java.util.List; import java.util.Map; import java.util.stream.Collectors; public class CustomerMapper { public static List<Customer> fromList(List<Map<String, AttributeValue>> items) { return items.stream() .map(CustomerMapper::fromMap) .collect(Collectors.toList()); } public static Customer fromMap(Map<String, AttributeValue> attributeValueMap) { Customer customer = new Customer(); customer.setId(attributeValueMap.get("customerId").s()); customer.setName(attributeValueMap.get("name").s()); customer.setEmail(attributeValueMap.get("email").s()); customer.setCity(attributeValueMap.get("city").s()); return customer; } public static Map<String, AttributeValue> toMap(Customer customer) { return Map.of( "customerId", AttributeValue.builder().s(customer.getId()).build(), "name", AttributeValue.builder().s(customer.getName()).build(), "email", AttributeValue.builder().s(customer.getEmail()).build(), "city", AttributeValue.builder().s(customer.getCity()).build() ); } }

4.2 Service

Next we are defining Spring’s Service class to abstract the repository from our routes (controller in old world) layer. Note that we are calling CustomerRepository from the service class and mapping the response into ServerResponse with appropriate Http Status.

CustomerService.java

package net.viralpatel.springbootwebfluxdynamodb.customer; import org.springframework.stereotype.Service; import org.springframework.web.reactive.function.BodyInserters; import org.springframework.web.reactive.function.server.ServerRequest; import org.springframework.web.reactive.function.server.ServerResponse; import reactor.core.publisher.Mono; import java.net.URI; import java.util.stream.Collectors; @Service public class CustomerService { private CustomerRepository customerRepository; public CustomerService(CustomerRepository customerRepository) { this.customerRepository = customerRepository; } public Mono<ServerResponse> listCustomers(ServerRequest serverRequest) { return customerRepository.listCustomers() .collect(Collectors.toList()) .flatMap(customers -> ServerResponse.ok().body(BodyInserters.fromValue(customers))); } public Mono<ServerResponse> createCustomer(ServerRequest serverRequest) { return serverRequest.bodyToMono(Customer.class) .flatMap(customer -> customerRepository.createCustomer(customer)) .flatMap(customer -> ServerResponse.created(URI.create("/customers/" + customer.getId())).build()); } public Mono<ServerResponse> deleteCustomer(ServerRequest serverRequest) { String customerId = serverRequest.pathVariable("customerId"); return customerRepository.deleteCustomer(customerId) .flatMap(customer -> ServerResponse.ok().build()); } public Mono<ServerResponse> getCustomer(ServerRequest serverRequest) { String customerId = serverRequest.pathVariable("customerId"); return customerRepository.getCustomer(customerId) .flatMap(customer -> ServerResponse.ok().body(BodyInserters.fromValue(customer))); } public Mono<ServerResponse> updateCustomer(ServerRequest serverRequest) { String customerId = serverRequest.pathVariable("customerId"); return serverRequest.bodyToMono(Customer.class) .flatMap(customer -> customerRepository.updateCustomer(customerId, customer)) .flatMap(customer -> ServerResponse.ok().build()); } }

4.3 REST API Webflux Routes

Finally we glue everything up using Routes.java. In this class we utilize Spring Webflux RouterFunctions to define the route endpoints for Customer REST API.

We defined a bunch of methods using GET, PUT, POST, DELETE methods in Spring Webflux RouterFunctions and invoked appropriate CustomerService methods.

Routes.java

package net.viralpatel.springbootwebfluxdynamodb; import net.viralpatel.springbootwebfluxdynamodb.customer.CustomerService; import org.springframework.context.annotation.Bean; import org.springframework.context.annotation.Configuration; import org.springframework.web.reactive.function.server.RouterFunction; import org.springframework.web.reactive.function.server.ServerResponse; import static org.springframework.web.reactive.function.server.RequestPredicates.*; import static org.springframework.web.reactive.function.server.RouterFunctions.route; @Configuration public class Routes { private CustomerService customerService; public Routes(CustomerService customerService) { this.customerService = customerService; } @Bean RouterFunction<ServerResponse> customers() { return route(GET("/customers"), customerService::listCustomers) .andRoute(POST("/customers"), customerService::createCustomer) .andRoute(GET("/customers/{customerId}"), customerService::getCustomer) .andRoute(PUT("/customers/{customerId}"), customerService::updateCustomer) .andRoute(DELETE("/customers/{customerId}"), customerService::deleteCustomer); } }

That’s All Folks

Build and execute the project using Gradle.

$ ./gradlew bootRun

Make sure your local instance of DynamoDB is up and running and customers table is created before starting the project. If everything is setup correctly, the customer API should be able to communicate with DynamoDB.

Open Postman and fire up the APIs.

Create new customer

Create Customer REST API Webflux DynamoDB

List all customers

List Customers REST API Webflux DynamoDB

Download – Spring Boot Webflux DynamoDB example

Source code of this project is available on Github.

Github – spring-boot-webflux-dynamodb

Further Reading

Get our Articles via Email. Enter your email address.

You may also like...

2 Comments

  1. MrBosski says:

    Nice article!

    While I agree that Docker is the way to go, I fail to see how it was easier to set up your example than using a local DynamoDB library – starting them up requires a one-liner in both cases but installing Docker on your local and build machines, plus adding a dependency in your build script vs just adding a dependency? Hmm, doesn’t really add up :)

    Also, why not use a dynamic free port instead of a fixed 8000 port?

    Btw, if you’re using a lot of AWS stuff, give localstack a try, great stuff for both integration testing and local development, bundles all the most frequently used AWS services into one library / container.

    • Thanks for the comments. I agree sometimes its just easy to use local library like this one instead of using Docker. However Docker does make it easy to run any container as it becomes like easy ritual to start an image and interact with it.

      In this example, I am just using 8000 port so I don’t have to change the config in my application.yaml to point DynamoDB client to it.

      Also, thanks for suggesting LocalStack. I have been playing a while with it and it really make it easy interacting with AWS locally. I will try to write few articles on that.
